Quantum Fresh™ High-Wall Series
Out of Stock
Pioneer® Quantum Fresh™ 12,000 BTU 24 SEER2 High-Wall Ductless Mini-Split Fresh Air Conditioner Inverter Heat Pump Full Set
Pioneer® Quantum Fresh™ 12,000 BTU 24 SEER2 High-Wall Ductless Mini-Split Fresh Air Conditioner Inverter Heat Pump Full Set
Regular price
$1,616.00
Sale price
$1,616.00
Regular price
$2,305.00
Out of stock
-
Estimated delivery if ordered today: Jul 20 - Jul 24
Couldn't load pickup availability
Payment & Security
Payment methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Why buy from our store?
Summary
- High Efficiency Quantum Fresh Ductless Mini Split Heat Pump System
- Cooling capacity: 12,000 BTU/H with 24 SEER2 / 13 EER2 efficiency
- Heating capacity: 13,100 BTU/H with 9.5 HSPF2 / 4.2 COP2 efficiency
- Voltage: 208/230V, 60Hz, 1Ph
- High Wall-Mounted Ductless Air Conditioning & Heating System
- Variable-Speed DC Inverter Driven Performance
- Factory-Precharged with Environmentally Friendly R32 Refrigerant
- Low Ambient Range Operation (As low as -4°F in Heating / As high as 122°F in Cooling)
Features
- Heat Pump with Cooling, Heating, Dry, and Ventilation Modes
- Fresh Air Infusion System - Brings in, Filters, and Mixes Outdoor Air to Replenish Indoor Oxygen
- Dual-Drainage Ports
- Washable, Reusable Air Filters
- Dual-Axis Airflow (Motorized Up-Down and Left-Right Louvers)
- Functional Remote with:
- ECO and SLEEP Modes, for Energy-Conservation
- Timer On/Off Control
- TURBO, for Times of High-Demand
- Self-Clean Cycle
- MEMORY, to Recall Favorite Settings
- IFEEL, to Detect and Adjust to Local Temperature
Technical Information & Performance
-
System Kit
- Power Supply: 208~230V, 60Hz, 1Ph
- Cooling Rated Capacity: 12,000 BTU/h
- Cooling Capacity Range: 3,000 ~ 15,000 BTU/h
- Cooling SEER2: 24.0 BTU/W.h
- Cooling EER2: 13.0 BTU/W.h
- Heating Rated Capacity: 13,100 BTU/h
- Heating Capacity Range: 3,000 ~ 13,600 BTU/h
- Heating HSPF2 (Region IV): 9.5 / 8.5 BTU/W.h
- Heating C.O.P.2 (47°F/5°F): 4.2 / 2.0 W/W
- Refrigerant Type: R32
- Suitable Area: 200~500 Sq.F
- AHRI Reference: 217048739
-
Indoor Unit
- Part Number: WT012GLUI25FVQ
- Air Flow (Turbo/Hi/Med/Lo/Mute): 440 / 410 / 380/ 230 / 150 CFM
- Fresh Air Volume: 18 CFM
- Sound Level (Turbo/Hi/Med/Lo/Mute): 44 / 43 / 37 / 32 / 30 dB(A)
- Product Dimensions (WDH): 36"-1/4 x 8"-1/8 x 12"-1/4 Inches
- Carton Dimensions (WDH): 39"-1/4 x 12"-1/4 x 15"-1/4 Inches
- Net / Gross Weight: 25.4 / 32.2 lbs.
-
Outdoor Unit
-
Part Number: YN012GLUI25RPQ
- Breaker Needed: 15A (double-pole)
- Sound Level: 53 dB(A)
- Net Dimensions (WDH): 31"-7/8 x 12" x 21"-5/8 Inches
- Carton Dimensions (WDH): 33"-1/2 x 14"-1/8 x 23"-5/8 Inches
- Net / Gross Weight: 55.1 / 61.7 lbs.
-
Part Number: YN012GLUI25RPQ
Dimension Chart
Quantum Fresh™ High-Wall Series
