Quantum Hyperformance™ High-Wall Series
Pioneer® Quantum Hyperformance™ 24,000 BTU 22.5 SEER2 230V High-Wall Ductless Energy-Star Mini-Split Air Conditioner Inverter Hyper Heat Pump Full Set
Pioneer® Quantum Hyperformance™ 24,000 BTU 22.5 SEER2 230V High-Wall Ductless Energy-Star Mini-Split Air Conditioner Inverter Hyper Heat Pump Full Set
Available in stock
-
Estimated delivery if ordered today: Dec 09 - Dec 13
Couldn't load pickup availability
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Why buy from our store?
Our Most Feature-Packed System
The Hyperformance system delivers ultra-quiet comfort, smart control from anywhere, and unbeatable performance in extreme cold.
Heats in -22°F Weather
When winter pushes its hardest, this system pushes back. Engineered to perform in extreme cold, it keeps your home warm and cozy even when outside temperatures plunge.
Pays Back from Day 1
Qualifies for the IRA 30% Federal Tax Credit and other local rebates, while delivering up to 25 SEER ultra high-efficiency performance. That means instant value AND long-term savings.
Free Phone App Control
Stay in command from anywhere with the Pioneer Airlink™ phone app. Adjust settings, schedule comfort, and monitor performance, right from your phone. Compatible with Google/Alexa/Siri.
Silence is the Standard
Advanced engineering delivers library-like quiet operation inside and out, so you can focus on life, not background buzz. With sound levels as low as 26dB, the only thing you'll notice is comfort.
Summary
- Ultimate Efficiency Quantum Hyperformance™ Ductless Mini Split Heat Pump System
- Cooling capacity: 24,000 BTU/H with 22.5 SEER2 / 11.7 EER2 efficiency
- Heating capacity: 24,000 BTU/H with 10.0 HSPF2 / 3.5 COP2 efficiency
- Voltage: 208/230V, 60Hz, 1Ph
- High Wall-Mounted Ductless Air Conditioning & Heating System
- Wi-Fi Enabled and Controllable By Smartphone via the Free Pioneer Airlink App
- Variable-Speed DC Inverter Driven Performance
- Factory-Precharged with Environmentally Friendly R454b Refrigerant
- Extreme Climate Operation (As low as -22°F in Heating / As high as 131°F in Cooling)
Features
- Heat Pump with Cooling, Heating, Dry, and Ventilation Modes
- Dual-Drainage Ports
- Washable, Reusable Air Filters
- Dual-Axis Airflow (Motorized Up-Down and Left-Right Louvers
- Functional Remote with:
- ECO and SLEEP Modes, for Energy-Conservation
- Timer On/Off Control
- TURBO, for Times of High-Demand
- Self-Clean Cycle
- MEMORY, to Recall Favorite Settings
- IFEEL, to Detect and Adjust to Local Temperature
Technical Information & Performance
-
System Kit
- Power Supply: 208~230V, 60Hz, 1Ph
- Cooling Rated Capacity: 24,000 BTU/h
- Cooling Capacity Range: 4,800~25,200 BTU/h
- Cooling SEER2: 22.5 BTU/W.h
- Cooling EER2: 11.7 BTU/W.h
- Heating Rated Capacity: 24,000 BTU/h
- Heating Capacity Range: 4,800~26,900 BTU/h
- Heating HSPF2 (Region IV): 10.0 BTU/W.h
- Heating C.O.P.2 (47°F/5°F): 3.5 / 1.8 W/W
- Refrigerant Type: R454b
- Recommended Room Size: 750~1,000 sq ft
- Minimum Room Size: 63 sq ft
- Minimum Installation Height: 6 ft
- Piping Diameter: 1/4 x 5/8"
- AHRI Reference: 217048757
-
Indoor Unit
- Part Number: WT024GLSI25HLH
- Air Flow (Turbo/Hi/Med/Lo/Mute): 735/676/529/423/394 CFM
- Sound Level (Turbo/Hi/Med/Lo/Mute): 49/47/42/37/32 dB(A)
- Product Dimensions (WDH): 43"-1/8 x 8"-3/4 x 13"-1/8 Inches
- Carton Dimensions (WDH): 45"-7/8 x 11"-5/8 x 16" Inches
- Net / Gross Weight: 30.9 / 35.3 lbs.
-
Outdoor Unit
- Part Number: YN024GLSI25RPH
- Breaker Needed: 30A (double-pole)
- Sound Level: 61 dB(A)
- Net Dimensions (WDH): 38"-1/2 x 16"-5/8 x 31"-5/8 Inches
- Carton Dimensions (WDH): 40"-1/4 x 18"-7/8 x 31"-7/8 Inches
- Net / Gross Weight: 108.0 / 116.8 lbs.
Dimension Chart
Quantum Hyperformance™ High-Wall Series
Questions & Answers
Have a Question?
-
Will the air conditioning run efficiently in cold climate weather in Minnesota?
Yes this is specifically designed for cold-climates and can continue heating in -22°F weather.
-
Does it come with a drain pan heater or low ambient kit
Yes it is built with the pan heater tech to allow for defrosting in freezing temperatures.
-
What is the lowest temperature setting available for heat on this unit. Thinking for a garage 1500 sq foot
Our units have a temp setting range of 61 - 86°F.They also a have a special "Freeze Protection"/Vacation Mode fixed setting of 46°F which is used to keep pipes from freezing.
